| ขั้นต่ำ: | 10 |
| ราคา: | 197 |
| standard packaging: | 10 ชิ้น / กล่อง |
| Delivery period: | 1-2 วัน |
| วิธีการจ่ายเงิน: | แอล/C, ที/ที |
| Supply Capacity: | 10,000 ชิ้น / สัปดาห์ |
The brand new TX16S Mark II remote control comes with an English OpenX menu, which can be flashed with Chinese EDGETX. A tutorial is available.
The firmware tutorial link is as follows:
https://www.bilibili.com/video/BV1EY411c7JC?spm_id_from=333.999.0.0
Specifications: 287 x 129 x 184 mm
Weight: 750 g (excluding battery)
Transmission Frequency: 2.400 GHz - 2.480 GHz
Transmitter Module (Optional):
Version 1: Built-in quad-protocol high-frequency module (CC2500 CYRF6936 A7105 NRF2401)
Version 2: Built-in ELRS (SX1280)
Transmit Power:
Built-in quad-protocol high-frequency module: Maximum 100 MW
Built-in ELRS: Maximum 250 MW (adjustable transmit power)
Antenna Gain: 2 dB
Operating Current: 400 mA
Operating Voltage: 6.6-8.4 V DC Remote Control Distance: >2KM@22DBM Open Source Firmware: EDGETX (Factory Default) Built-in Module: MULTIPROTOCOL-MODULE (4IN1)-OR-EXPRESSLRS (ELRS) Number of Channels: Up to 16 channels (depending on receiver) Display: 4.3-inch TFT full-color display, resolution 480*272 Joystick: V4.0 Hall effect joystick or AGO1 Hall effect joystick (upgradeable) External Module Compartment: Standard JR compartment size Upgrade Method: Supports USB online/SD card offline upgrade
Improved internal circuity and optimized power supply.
• New charge circuitry with integrated reverse-polarity protection.
• Optimized charge IC, better balancing and USB-C charge current management.
• Rear mounted audio jack provides headphone output.
• V4.0 Gimbal improved centring and temperature stability (Same circuitry as AG01).
• Optional high/low rear grips included for improved ergonomics.
• Improved S1/S2 knobs with clear centre-detents.
• Improved LS/RS Sliders with smoother feel and better centre-detents.
• Redesigned battery cover for improved battery access.
• Retooled body shell with improved fit and finish.
• Trainer socket changed to standard TRS 3.5mm socket.
• Rear DIY Socket added for personalised mods.
• Available ELRS and 4in1 versions.
MAX units feature carbon look face plates and CNC finishing components and buttons.
FAQ:
|
|
